The NABCO swing door operator automates a hinged door. It is the answer where there is no room for a sliding door case, and the usual route for converting an existing manual entrance to automatic operation, which makes it the standard accessibility upgrade in buildings already in use. A power assist version is available where a lighter push is wanted rather than full automation.
Key Features
- Single or double swing, with a power assist option for doors that only need help rather than full automation.
- Retrofit friendly, converts an existing manual swing door without a door case or structural alteration.
- Independent open and close speeds, adjustable on commissioning to suit traffic and door mass.
- Supplied and installed by Elite Radio, following a site survey, with installation covered in your project quotation.
Why Buy from Elite Radio
Elite Radio & Engineering Co. is the sole importer and authorised agent for NABCO in Sri Lanka, established 1959. Every door is genuine Nabtesco equipment, surveyed, installed and commissioned by our own engineering team, and backed by islandwide service, spares and scheduled maintenance from our Colombo base.
Specifications
- Brand: NABCO (Nabtesco, Japan)
- Type: Swing door operating unit, single or double swing, power assist option
- Applicable door mass: 90 to 110 kg per leaf depending on operator
- Referential door size: 750 x 2100 mm to 1000 x 2400 mm (framed door)
- Applicable door width: 838 to 1219 mm (power assist)
- Open speed: variable, under 0.45 degrees per second
- Close speed: variable, under 0.30 to 0.45 degrees per second
- Maximum operable wind speed: 10 m/s or less
- Application: office buildings, accessibility upgrades, interior doors
- Warranty: NABCO manufacturer warranty plus Elite Radio workmanship cover (contact us for current terms)
Operator model, power supply and controls for the Sri Lanka market are confirmed at quotation, after a site survey of the existing door and frame.
